28 Inch Stretched LCD Display with 700 cd/m² Brightness 1920*360 Pixels and 51Pin Connector for Digital Signage

Product Categories
FOCUS VISION TECHNOLOGY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

28 Inch Stretched LCD Display with 700 cd/m² Brightness 1920*360 Pixels and 51Pin Connector for Digital Signage

  • 1
  • 2
  • 3

Brand Name : BOE

Model Number : DV280FBM-NB1

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W,Western Union,MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

material : glass led

color : 16.7M

model : WLED,LCD

style : wide screen high resolution 1920*1080pixels

resolution : 3840*720

brightness : 700CCD/M2

connector : 51Pin

working life : 50k hours

contrast ratio : 1200:1

Contact Now

BOE bar LCD display 28" DV280FBM-NB1 stretch lcd display 700CCD/M2 1920*360ixels for advisement player 16.7M colors

Panel Brand
Panel Size
Resolution
Display Area
Outline Size
Brightness
Viewing Angle
Best View on
Display Colors
Frequency
Weight
BOE
28.0 inch (1/3 cut of 31.5")
1920(RGB)×360
699.84(W)×131.22(H) mm
732(W)×165(H) mm
700 cd/m² (Typ.)
89/89/89/89 (Typ.)(CR≥10)
Symmetry
16.7M 72% (CIE1931)
60Hz
2.40Kgs (Typ.)
Panel Model
Panel Type
Pixel Format
Bezel Opening
Surface
Contrast Ratio
Display Mode
Response Time
Lamp Type
Touch Screen
Application
DV280FBM-NB1
a-Si TFT-LCD , LCM
RGB Vertical Stripe
704(W)×136(H) mm
-
1200:1 (Typ.) (TM)
ADS, Normally Black, Transmissive
8 (Typ.)(G to G)
WLED , 30K hours , Without Driver
Without
Signal Interface LVDS (1 ch, 8-bit) , 51 pins , Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

28 Inch Stretched LCD Display with 700 cd/m² Brightness 1920*360 Pixels and 51Pin Connector for Digital Signage28 Inch Stretched LCD Display with 700 cd/m² Brightness 1920*360 Pixels and 51Pin Connector for Digital Signage

28 Inch Stretched LCD Display with 700 cd/m² Brightness 1920*360 Pixels and 51Pin Connector for Digital Signage28 Inch Stretched LCD Display with 700 cd/m² Brightness 1920*360 Pixels and 51Pin Connector for Digital Signage

All our LCD LED screen monitor module panel products will be full test one by one before sending .
